Jeep Grand Cherokee Touchscreen GPS Navigation DVD Car Stereo (2014-2015)
Jeep Grand Cherokee Touchscreen GPS Navigation Head Unit has a 7 inch 16:9 TFT digital touch screen. It can support RDS function for EU and AU market, and you retain all your original steering wheel controls. You get the ability to play DVDs onthe touchscreen, in-dash GPS Navigation, bluetooth for handsfree calling and for audio streaming of your music, Pandora, or satellite radio, plus additional tools and apps.
This unit is designed for:
Jeep Grand Cherokee: 2014, 2015
NOTE: The Factory amplified system with subwoofer will not work with this radio. The factory amplifier is not receiving power from our radio.
NOTE: The factory backup camera will not display on the screen without splicing a standard RCA video plug into the wiring harness so that it can plug into the camera RCA input on the radio. (You can view the wiring diagram here)
Works to replace Uconnect factory radios on the new Jeep Grand Cherokee. This radio is a direct upgrade, and it uses the factory wiring harness. It is truely plug-and-play. To install, remove the factory radio, and install this one in it's place. The fit is perfect, and all the factory wires simply plug into the radio. It also comes with additional wiring harnesses in case you want to add outputs for amplifiers or video screens, as wel as input harnesses for DVRs and gaming systems.
The radio is very well integrated with the factory wiring. Not only does it connect to all the speakers and the steering wheel controls (if equipped) but is also displays on the touchscreen when the door is opened and when the temperature of fan speed climate control settings are changed.
Note above year range is for your reference only. Check with us if you are not sure about fitness.
SPECIFICATIONS
Operating System | ||
System Operation | Wince 6.0 | |
Start-up | Less than 5 seconds | |
Operation | Push-button/Touch screen/Steering wheel controls/Remote | |
Hardware | ||
CPU | 1GHz Dual-Core A8 chipset | |
RAM | DDR II 512MB | |
ROM | 4GB Flash, external SD 32G maximum | |
Screen | 7 inch 800*480px HD touchscreen, 65000 color | |
Bluetooth | 2.402GHZ-2.480GHZ ISM Band | |
Network | 3G, WiFi | |
Amplifier | Built-in DSP sound amplifier | |
Video decoder | 1080p HD video | |
Navigation Software | ||
Navigation Software | iGO Primo | |
3D Maps | Support | |
TTS | Support | |
Sync Time |
Automatically |
|
Languages | More than 30 main language around the world | |
Updatable | Yes, get the latest maps from our website for free! |
INSTALLATION PHOTOS
FUNCTIONAL DESCRIPTION
Navigation * Free maps preload and free updates |
DVD * Support DVD/VCD/CD/MP3/MP4/WMA/ * 20 Virtual discs changer, load as much |
|||
Radio * Built-in AM/FM tuner * DOES NOT HAVE SATELLITE RADIO TUNER |
iPod * Control iPod music through touchscreen directly |
|||
Bluetooth * Hands free phone call |
SD/USB * SD/USB music, video, photo and ebook |
|||
Backup Camera & Parking Radar (Optional) * Display reverse image automatically |
|
DVR (Optional) * Support forward video |
||
TV (Optional) * Support ATSC For North America |
AUX * One channel AUX input for external device
|
|||
SWC * Compatible with CANBUS and original steering wheel |
Network (Optional) * 3G, WiFi (network adapter not included) |
SCREEN SHOTS:
Main Menu | Media Menu |
Radio | Audio Player |
Bluetooth Phone Call | A2DP |
iPod Playlist |
iPod |
FUNCTIONAL DETAILS
