This BMW radio has a 6.2 inch touch screen, it is designed to replace stock radio system, totally plug and play, no need to cut wires, the same UI as BMW OEM navi system, free gps navigation map preloaded for your country. It comes with CANBUS decoder, can support the original air condition information, steering wheel control and heated seat. This unit fits to:

BMW 3 Series E90 Saloon 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013
BMW 3 Series E91 Touring 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013
BMW 3 Series E92 Coupe 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013
BMW 3 Series E93 Cabriolet 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013

Note above year range is for your reference only. Check with us if you are not sure about fitness.

Attention: This unit only fit to manual air conditioning version, you need model HL-8798GB if your vehicle is automatic air conditioning version.

• Screen: TFT(800*480px) digital touchscreen

• Audio: 4 x 52w, 4 Channel line-out

• EQ control: Bass, Treble, Balance and Fade

• Video Systems: PAL, NTSC, AUTO

• Video Compatibility: DVD, DVD-R, DVD-RW, HDVD, DVCD, MP3, MP4, CD-R, CD-RW, VCD, DIVX(MPEG-4) etc. Can support
• high definition video(1080P)

• Video output/input: One set video output(Audio Out L, Audio Out R, Video Out) and one set video input(AUX-IN L, AUX-IN R,
• AUX-VIDEO IN)

• Radio receiving: High sensitive FM/AM tuner 50 stations restorable, support RDS function, diaplay radio station name

• AM Frequency Range: 522-1710KHz (Worldwide)

• FM Tuning Range: 87.5-108.0MHz (Worldwide)

• iPod Control: Support music, NOT support video

• Bluetooth: Phonecall, phonebook and A2DP Bluetooth music stream

• USB drive: Support multimedia, support 32GB capacity

• SD card: Dual card slots, one is for GPS software, another one is for multimedia files, support 32GB capacity

• Steering Wheel Control: Support original steering wheel controls like Vol+/-, Pre/Next, Mode etc.

• Power Supply: DC 10-14.6V

• Working Temperature: -20-80 degree c

• Navigation System: Operation system: WINCE 6.0 CORE

• GPS maps: Support map: Tomtom, iGO(Primo), Route66, Navitel, Garmin. etc.

• Voice navigation: Support TTS voice navigation

• Dual zone: Support navigation while listen to music at the same time

• Analog TV: Built-in analog TV system, ATV antenna is not included

• Digital TV: DVB-T, DVB T2, ATSC, ISDB-T: Optional

• Rearview camera: automatic reversing rearview when reversing: Optional

• Parking radar: show distance on monitor when reversing: Optional



Software
System Operation		Wince 6.0
Navigation System		iGO Primo
Hardware
CPU		800 MHZ
RAM		DDR II 256MB
ROM		4GB Flash
Screen		800*480px HD touchscreen, 65000 color
Bluetooth		2.402GHZ-2.480GHZ ISM Band
HD Video		Support 1080p HD video
GPS Receiver
Frequency		1575.42MHZ C/A CODE
Protocol standard		NMEA-0183 V3.01
Channel		22 channel for tracking
Tracking Sense		-164dBm
Locate		3m 2D RMS



INSTALLATION PHOTOS

none

FUNCTIONAL DESCRIPTION

		Intelligent Navigation * Map data with ongoing update for free * Support real 3D map * Intelligent Text-to speech direction * Automatic route plan * Advanced point of interest management				Bluetooth * Hands free phone call, call history * Phone book from you phone, caller ID display * Bluetooth music stream A2DP
		Radio * Built-in AM/FM tuner * Support RDS * Can work in countries all over the world				AUX * One channel AUX input for external audio device * Two channel AUX output for rear headrest monitor
		iPod * Control iPod music through touchscreen * Support iPod music * Support iPod video(cable optional) * Charge iPod while playing				SD/USB * SD/USB music, video, photo and ebook * maximum capacity as large as 32GB * File management
		DVD * Support DVD/VCD/CD/MP3/MP4/WMA/CD-R/MPEG4/JPG format disc				SWC * Come with CANBUS decoder for original steering wheel control, car info and amplifier audio system
		Backup Camera & Parking Sensor * Display back image automatically once you shift the gear * Beep warning when vehicle is close to the obstacle * Display guard Line and distance on the reverse image				TV Tuner * Support ATSC For North America * Support DVB-T For Europe/Australia Countries * Support ISDB-T For South America
		Dual Zone Entertainment * Kids can watch DVD from headrest monitor on your back seats while Navi working and voice guide from front speakers.				TMC(optional) * Traffic Message Channel (TMC) support, please leave a message if you need this function when place order



SCREEN SHOTS

Main Menu		Main Menu



Radio		Audio Player



Bluetooth Phone Call		A2DP



iPod		iPod Playlist
